| Model | Flow Capacity (N㎥/min) |
Power consumption |
Ambient Temp Range |
Inlet Temp Range |
Electric Outlet |
Refrigerant | Drain Trap | Inlet/Outlet | Dimension | Weight | |
|---|---|---|---|---|---|---|---|---|---|---|---|
| 50Hz | 60Hz | Kw | ℃ | ℃ | V/ph | Type | PT/FLG | LxWxH(mm) | kg | ||
| KWD-10B-1 | 1.0 | 1.2 | 0.47 | 2~40 | 4~50 | 220V/ 1ph |
R-134a | Float | PT 3/4＂(20A) | 578x180x510 | 21 |
| KWD-15B-1 | 1.5 | 1.8 | 0.47 | PT 3/4＂(20A) | 600x240x510 | 26 | |||||
| KWD-20B-1 | 2.2 | 2.6 | 0.50 | R-410a | PT 1＂(25A) | 660x240x580 | 31 | ||||
| KWD-35B-1 | 3.9 | 4.7 | 0.52 | Disk | PT 1＂(25A) | 780x240x609 | 40 | ||||
| KWD-50B-1 | 5.6 | 6.8 | 0.94 | PT 1 1/2＂(40A) | 870x240x616 | 43 | |||||
| KWD-75B | 8.6 | 10.5 | 1.30 | R-22 | PT 1 1/2＂(40A) | 912x347x887 | 72 | ||||
| KWD-100B | 11.0 | 14.0 | 1.70 | PT 2＂(50A) | 912x347x887 | 78 | |||||
| KWD-150B | 17.0 | 20.0 | 3.00 | FLG 2 1/2＂(65A) | 859x572x1170 | 165 | |||||
| KWD-200B | 25.0 | 30.0 | 3.10 | FLG 3＂(80A) | 859x572x1170 | 168 | |||||
- Flow capacity is based on conditions:
35°C inlet temperature, 7.0 barG inlet pressure, 100% relative humidity, 32°C ambient temperature, pressure dew point 5°C, air-cooled type.
